Helios

Hybrid Spot Fixture

All-in-one versatile, compact moving head luminaire. It features a variable 7-to-36 degree motorized zoom range, a 9-way static gobo wheel, a 9-way rotating interchangeable gobo wheel, and an indexable 4-way prism. It is driven by a potent 250W 7000K LED engine carrying a comprehensive built-in FX graphics package.

3-in-1 True Versatility

Full Beam, Spot, and Wash tracking
Powerful 250W 7000K LED engine
Interchangable gobos

Advanced Beam Controls

Motorized 7° to 36° zoom range
Indexable 4-way rotating prism
7 vibrant dichroic colour filters

Touring Ready

9 static + 9 rotating gobo wheels
Full built-in graphics FX suite
Includes folding quick clamps

Gallery

Technical Specifications

Light source: 250W 7000K LED Engine
Zoom Range: 7°-36°
Connections: PowerCON In & Link | 5 Pin DMX
7 colors with 1 CTB Filter, plus open
1 x 9-Way Staic Gobo Wheel
1 x 9-Way Rotating & Interchangable Gobo Wheel
Indexable 4-way Prism
DMX Modes: 17, 21 Ch
Lifetime: up to 50,000 hours*
Protection class: IP30
Input voltage: 110-240V~ 50/60Hz
Weight: 16,2 KGs
Warranty: 12 Months
Includes folding clamps
Flicker free LED engine

Custom Gobos:
Gobo Diameter: 23.8mm, Image Diameter: 14mm

Gobo Set

Bundle

Sold as a bundle set including:
2x Helios Hybrid
Folding Clamps
Safeties
Power Cabling
Flightcase

Library Downloads:

Documents:
